Cardo Spirit HD Intercom with Premium Features (SPRT0002)

Cardo SPIRIT HD Intercom with Premium Features - SPRT0002

The Cardo SPIRIT HD sets a new standard for entry-level motorcycle communication with premium features. It combines an upgraded rider-to-rider intercom range of up to 600 meters, powerful 40mm HD speakers, 13 hours of talk time, built-in FM radio, Bluetooth 5.2, waterproof and dustproof construction, universal connectivity, automatic volume adjustment, and wireless over-the-air software updates.

The Cardo SPIRIT HD is Cardo's premium-feature entry-level rider-to-rider communicator, designed to provide clear communication, reliable connectivity, and high-quality audio for everyday motorcycle riding.

With powerful 40mm HD speakers, an advanced processor, three uniquely designed sound profiles, wideband Bluetooth intercom, USB Type-C fast charging, and a built-in FM radio with RDS, the SPIRIT HD provides an enhanced riding experience in a compact and practical package.

Key Features

• HD Speakers: Powerful 40mm HD speakers, an advanced processor, and 3 uniquely designed sound profiles deliver an enhanced audio experience.
• Wideband Intercom: Crystal-clear Bluetooth intercom communication for 2 riders with a range of up to 600m / 0.4mi.
• Waterproof & Dustproof: Designed to keep you connected through rain, shine, mud, dust, and snow.
• Over-the-Air Software Updates: Download and install the latest software directly through the Cardo Connect App without cables.
• Universal Connectivity: Connects with Bluetooth headsets from Cardo and other brands.
• Automatic Volume: Automatically adjusts audio volume according to surrounding ambient noise.
• FM Radio: Built-in FM radio with RDS for automatic selection of the strongest available signal.
• Music Streaming: Stream music directly from your smartphone and control your favorite tunes while riding.
• Phone & GPS: Make calls and control GPS functions using buttons or voice commands.
• Fast Charging: Get up to 2 hours of talk time after only 20 minutes of charging.
• USB Type-C: Robust and universal USB Type-C connection for convenient charging.
• Bluetooth 5.2: Advanced Bluetooth technology offering faster pairing, improved efficiency, enhanced security, and longer battery performance.
• 13-Hour Talk Time: Provides up to 13 hours of talk time on a full charge.
• 2-Year Warranty: Includes a two-year warranty.

Highlights

• Waterproof and dustproof construction.
• Up to 600m / 0.4mi rider-to-rider Bluetooth intercom range.
• 2-way Bluetooth intercom for up to 2 riders.
• Universal connectivity.
• Over-the-Air software updates.
• Automatic volume adjustment.
• Bluetooth 5.2.
• Powerful 40mm HD speakers.
• Built-in FM radio with RDS.
• 13 hours of talk time.
• USB Type-C fast charging.

Product Specifications

Product Code: SPRT0002

Compatibility: Universal

Operating Temperature: -20°C to 55°C / -4°F to 131°F

Waterproof: Yes

FM Radio: Operating frequencies 76-108 MHz; RDS – Radio Data Systems; 6 preset station memories

Software Updates: Over-the-air updates and USB cable updates

Device Settings: Cardo Connect App

Main Unit Dimensions: Height 47mm, Length 78mm, Depth 19mm

Main Unit Weight: 35g

Speaker Dimensions: Diameter 40mm, Depth 10mm

Connectivity: 2 channels for mobile phone and GPS; Bluetooth 5.2; Universal connectivity; TFT connectivity

Intercom: Universal Bluetooth intercom

Group Size: Up to 2 riders

Intercom Range: Up to 600m / 0.4mi

User Interface: Multilingual status announcements

Audio: 40mm HD speakers; HD Audio profiles; Automatic Volume Control

Battery Talk Time: Up to 13 hours

Charging Time: Up to 2 hours

Fast Charging: Up to 2 hours of talk time after 20 minutes of charging

Standby Time: Up to 10 days

Certificates: CE, IC/FCC, SIG, BT, TELEC, UKCA

Frequently Asked Questions

How can I improve my sound quality?

Sound quality is best when the speakers are placed directly opposite your ear canal. With the helmet on, slide your finger inside the helmet and press against the side where your ear is located. This is where the speakers should be positioned.

Remove the helmet while keeping your finger in that position and check that the speakers are correctly aligned. Position the speakers as close to your ears as possible. If necessary, use the included Velcro booster pads behind the speakers to bring them closer to your ears.

Since every rider's head and every helmet are different, the helmet's ear cavities may not always provide the optimal speaker position. If necessary, position the speakers outside the helmet ear cavities, directly opposite your ears.

Can I use my unit in the rain?

Yes. The Cardo SPIRIT HD is waterproof and designed to keep you connected while riding in rainy and challenging weather conditions.

How long does it take to charge my unit?

The SPIRIT HD features Fast Charging. You can get up to 2 hours of talk time after only 20 minutes of charging. A full charge takes up to 2 hours.

How can I get more run-time out of my battery?

The Cardo unit supports charging while riding. You can connect the unit to a power bank or motorcycle power source and continue using it beyond the standard battery runtime.

Can I replace the battery in my unit?

Do not attempt to disassemble or replace the battery yourself. Replacing the battery yourself could damage the waterproof capability of the system.

If the battery is not holding a charge, connect the unit to its charger and leave it charging for at least 4 hours. If this does not resolve the issue, try a different wall charger and USB cable. If the unit still does not hold a charge, contact support.

The unit doesn't seem to be charging or the battery doesn't last as long as it should. What should I do?

Connect the unit to the charger and leave it charging for at least 4 hours. If this does not resolve the issue, try using a different wall charger and USB cable. If the unit still does not charge, contact support.

Do not open or disassemble the unit. Opening the unit can compromise its waterproof capability. Cardo does not recommend replacing internal parts yourself because of the risk of water, dirt, and general electronics damage.

How do I make sure that my unit's battery lasts as long as possible?

Do not leave your unit unused or in storage for more than 3 months without charging. It is recommended to charge the unit for a full 4 hours at least once every 3 months to help maintain maximum battery performance.

Which mobile app do I need to download?

You need to download the Cardo Connect App. The Cardo Connect App allows you to configure your unit, control functions remotely from your smartphone, and perform over-the-air software updates.

Does the SPIRIT line connect to other generations of Cardo units?

Yes. The SPIRIT line can connect to other Cardo communication systems through universal Bluetooth connectivity. FREECOM+ and PACKTALK units can connect with the SPIRIT unit using regular Bluetooth pairing. G and Q units need to be in phone pairing mode before starting the pairing process.

How do I pair to a non-Cardo headset using universal connectivity?

To pair your SPIRIT HD with a non-Cardo Bluetooth headset, start intercom pairing on your SPIRIT HD according to the pocket guide or user manual. On the other headset, start mobile phone pairing and wait for the pairing process to complete.

Can I listen to music and be part of the intercom at the same time?

Yes. Intercom and music streaming can be active at the same time. Whenever someone in the intercom network speaks, the Cardo unit automatically lowers the music volume so you can hear the conversation.

Something stopped working on my SPIRIT unit. What should I do?

Before trying anything else, Cardo recommends resetting the unit to factory settings.

• Step 1: Press the Intercom/Mobile, Volume Up, and Volume Down buttons together for at least 5 seconds until the LED starts flashing purple and the unit turns off.
• Step 2: Turn the unit back on.

Why can't I get the full range of intercom out of my unit?

The range stated in the product description has been tested under optimal conditions. Actual range performance may be adversely affected by obstacles that interfere with line of sight, such as mountains, trees, and power lines.

Are there limitations in using the music sharing feature?

Music sharing is possible between FREECOM X and SPIRIT units, but it is not possible to share music with other generations of Cardo units.

Is it possible to use it with my own earbuds or speakers?

Yes. While the SPIRIT HD comes with high-quality speakers, you can connect your preferred earbuds or aftermarket speakers through the 3.5mm jack port.

Do I need a phone to operate my unit?

The intercom and radio features are completely phone independent. You do not need a phone to use these features. A phone or another Bluetooth media player is required for music streaming, and a phone is required to make and receive calls.

How can I get more range of intercom out of my unit?

The stated intercom range is measured under optimal conditions. Actual performance may be affected by several environmental factors, including:

• Riding environment, including urban and non-urban areas.
• Topography.
• High-voltage power lines and cellular towers.
• Line of sight.

What’s in the Box?

• Cardo SPIRIT HD x 1 Kit
• SPIRIT Unit x 1
• Cradle x 1
• Glue Plate x 1
• Set of 40mm HD Speakers x 1
• Hybrid-Boom Microphone x 1
• Wired Microphone x 1
• USB Cable x 1
• Alcohol Prep Pads x 2
• Booster Pads x 2
• Rectangular Velcros x 2
• Round Velcros x 2
• Pocket Guide
• Installation Guide
